Welcome back to the channel, where today's video is all about upgrading the tail lights on your Bronco. Specifically, we'll be focusing on the Illuminate Tail Lights from Buckle Up Off-Road, designed to give your vehicle a sleek and customized look. In this step-by-step guide, we'll walk you through the installation process, all without the need for Forscan adjustments.

If you're after a unique and personalized touch for your Bronco, the Lumen8 Tail Lights are a must-have. Available in smoked and red LED options, and offer two start up sequences chase & swell, they not only look great but also offer the convenience of sequential turn signals.

Tools Required: Before diving into the installation process, make sure you have the following tools on hand:

  • Phillips Screwdriver
  • 10mm Socket
  • 8mm Socket

Step-by-Step Installation:

  1. Removing the Panel:

    • Using the Phillips screwdriver, carefully remove the push pins securing the panel.
    • Loosen the two clips near the flare of the Bronco.
    • Gently pop off the panel.
  2. Uninstalling the Original Tail Lights:

    • Utilize a 10mm socket to remove the bolt at the bottom.
    • Use an 8mm socket to remove the two bolts on the side.
    • Carefully detach the tail light from the vehicle.
  3. Addressing the Dip Switches:

    • If you have an LED-equipped Bronco, set the dip switches as follows:
      • For the swell opening sequence: Switch 1 off, Switch 2 on.
      • For the chase sequence: Switch 1 off, Switch 2 off (as demonstrated in this installation).
  4. Installing the Lumen8 Tail Lights:

    • Plug in the wiring harness, ensuring a secure connection.
    • Reattach the tail light using the same bolts in reverse order.
  5. Finalizing the Installation:

Repeat the above steps for the other tail light.
Enjoy the enhanced look and functionality of your new Lumen8 Tail Lights.

Though it's challenging to fully capture the effects on camera, we've done our best to showcase the chase sequence and sequential turn signals. Keep in mind that any flickering or flashing seen in the video is a result of camera limitations, not the actual tail lights.


With the Lumen8 Tail Lights installed, your Bronco is bound to turn heads on and off the road. For more details and to explore a wide range of Bronco accessories, head over to Buckle Up Offroad's website. Stay tuned for more exciting updates, and as always, Buckle Up, Buttercup!
